Description
Technical data
- Width: 3m/4m/5m
- Height dimension: 2.5m
- Center height: 2.85m/2.95m/3.05m
- Roof pitch: 22°.
- Portion width: 3m
- Length portion: 3m/4m/5m
- Minimum length: 6m
- Maximum length: Unlimited
- Profile structure: 87mm x 47mm x 2.5mm
- Pre-roof connection: Internal insertion of the eaves
- Max wind speed: 80 km/h
- Wind resistance: 0.3 kN/m².
- Floor option: Wood and steel flooring. Aluminum and wood or all-aluminum substructures.
- Covering: Polyester textile 650-900g / m2 covered with PVC, flame retardant to DIN 4102 B1 M2
