Description
Technical data
- Width: 10m
- Height dimension: 2.50m (Max: 4m)
- Center height: 4.41m
- Roof pitch: 18°.
- Span: 5m
- Minimum length: 3m
- Maximum length: Unlimited
- Profile structure: 166mm x 88mm x 3mm
- Pre-roof connection: Internal insertion of the eaves
- Max. wind speed: 100 km/h
- Wind resistance: 0.5 kN / m².
- Floor option: Wood and steel flooring. Aluminum and wood or all-aluminum substructures.
- Cover: Fireproof PVC tarpaulin to DIN 4102 B1 M2 + Rigid glass panels on aluminium frame
- Side walls: Glass panels + Aluminium + Double pedestrian access door –
- Roof : PVC 850g/m2 opaque –
